domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | ||||||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 1.2 | 2.4 | 3.6 | 4.8 | 6 | 7.2 | 8.4 | 9.6 | 10.8 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 20 | 40 | 60 | 80 | 100 | 120 | 140 | 160 | 180 | |||||||||
| 4sdm8/5 | 4sd8/5 | 0.55 | 0.75 | h(m) | 31 | 29 | 28 | 26 | 25 | 23 | 21 | 17 | 13 | 8 | 1¼" 1½" 2" | 415 | 729 | 719 | |
| 4sdm8/7 | 4sd8/7 | 0.75 | 1 | 43 | 41 | 39 | 37 | 34 | 32 | 29 | 24 | 18 | 11 | 1¼" 1½" 2" | 491 | 825 | 805 | ||
| 4sdm8/9 | 4sd8/9 | 1.1 | 1.5 | 56 | 53 | 50 | 47 | 44 | 41 | 37 | 31 | 23 | 14 | 1¼" 1½" 2" | 567 | 926 | 901 | ||
| 4sdm8/13 | 4sd8/13 | 1.5 | 2 | 80 | 76 | 72 | 68 | 64 | 59 | 54 | 45 | 33 | 21 | 1¼" 1½" 2" | 719 | 1129 | 1079 | ||
| 4sdm8/17 | 4sd8/17 | 2.2 | 3 | 105 | 100 | 95 | 89 | 84 | 78 | 70 | 59 | 44 | 27 | 1¼" 1½" 2" | 871 | 1396 | 1326 | ||
| - | 4sd8/21 | 3 | 4 | 130 | 123 | 117 | 110 | 103 | 96 | 87 | 73 | 54 | 33 | 1¼" 1½" 2" | 1054 | - | 1549 | ||
| - | 4sd8/24 | 3 | 4 | 148 | 141 | 134 | 125 | 118 | 110 | 99 | 84 | 61 | 38 | 1¼" 1½" 2" | 1168 | - | 1663 | ||
| - | 4sd8/28 | 4 | 5.5 | 173 | 165 | 156 | 146 | 138 | 128 | 116 | 98 | 72 | 44 | 1¼" 1½" 2" | 1320 | - | 1875 | ||
| - | 4sd8/32 | 4 | 5.5 | 197 | 188 | 178 | 167 | 157 | 146 | 133 | 112 | 82 | 51 | 1¼" 1½" 2" | 1472 | - | 2027 | ||
| - | 4sd8/36 | 5.5 | 7.5 | 222 | 212 | 200 | 188 | 177 | 164 | 149 | 126 | 92 | 57 | 1¼" 1½" 2" | 1624 | - | 2260 | ||
| - | 4sd8/40 | 5.5 | 7.5 | 247 | 235 | 223 | 209 | 197 | 183 | 166 | 140 | 103 | 63 | 1¼" 1½" 2" | 1808 | - | 2443 | ||
| - | 4sd8/44 | 7.5 | 10 | 271 | 259 | 245 | 230 | 216 | 201 | 182 | 154 | 113 | 70 | 1¼" 1½" 2" | 1960 | - | 2685 | ||
| - | 4sd8/48 | 7.5 | 10 | 296 | 282 | 267 | 251 | 236 | 219 | 199 | 168 | 123 | 76 | 1¼" 1½" 2" | 2112 | - | 2837 | ||
