domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | |||||||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 1.2 | 2.4 | 3.6 | 4.8 | 6 | 7.2 | 8.4 | 9.6 | 10.8 | 12 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 20 | 40 | 60 | 80 | 100 | 120 | 140 | 160 | 180 | 200 | |||||||||
| 4sdm10/4 | 4sd10/4 | 0.55 | 0.75 | h(m) | 23 | 23 | 22 | 21 | 21 | 20 | 19 | 17 | 15 | 13 | 9 | 1¼" 1½" 2" | 376 | 691 | 681 | |
| 4sdm10/6 | 4sd10/6 | 0.75 | 1 | 35 | 34 | 33 | 32 | 31 | 29 | 28 | 25 | 22 | 19 | 14 | 1¼" 1½" 2" | 452 | 787 | 767 | ||
| 4sdm10/8 | 4sd10/8 | 1.1 | 1.5 | 47 | 46 | 44 | 43 | 41 | 39 | 37 | 34 | 30 | 25 | 18 | 1¼" 1½" 2" | 528 | 888 | 863 | ||
| 4sdm10/10 | 4sd10/10 | 1.5 | 2 | 59 | 57 | 56 | 54 | 52 | 49 | 46 | 42 | 37 | 31 | 23 | 1¼" 1½" 2" | 605 | 1014 | 964 | ||
| 4sdm10/12 | 4sd10/12 | 2.2 | 3 | 70 | 69 | 67 | 64 | 62 | 59 | 56 | 51 | 45 | 38 | 27 | 1¼" 1½" 2" | 681 | 1205 | 1135 | ||
| 4sdm10/14 | 4sd10/14 | 2.2 | 3 | 82 | 80 | 78 | 75 | 72 | 69 | 65 | 59 | 52 | 44 | 32 | 1¼" 1½" 2" | 757 | 1281 | 1211 | ||
| - | 4sd10/16 | 3 | 4 | 94 | 92 | 89 | 86 | 83 | 79 | 74 | 68 | 60 | 50 | 36 | 1¼" 1½" 2" | 833 | - | 1327 | ||
| - | 4sd10/18 | 3 | 4 | 106 | 103 | 100 | 96 | 93 | 88 | 83 | 76 | 67 | 56 | 41 | 1¼" 1½" 2" | 909 | - | 1403 | ||
| - | 4sd10/21 | 4 | 5.5 | 123 | 120 | 117 | 113 | 109 | 103 | 97 | 89 | 79 | 66 | 47 | 1¼" 1½" 2" | 1054 | - | 1609 | ||
| - | 4sd10/24 | 4 | 5.5 | 141 | 137 | 133 | 129 | 124 | 118 | 111 | 102 | 90 | 75 | 54 | 1¼" 1½" 2" | 1168 | - | 1723 | ||
| - | 4sd10/27 | 5.5 | 7.5 | 158 | 155 | 150 | 145 | 140 | 133 | 125 | 115 | 101 | 85 | 61 | 1¼" 1½" 2" | 1282 | - | 1917 | ||
| - | 4sd10/30 | 5.5 | 7.5 | 176 | 172 | 167 | 161 | 155 | 148 | 139 | 127 | 112 | 94 | 68 | 1¼" 1½" 2" | 1396 | - | 2031 | ||
| - | 4sd10/34 | 7.5 | 10 | 199 | 195 | 189 | 182 | 176 | 167 | 158 | 144 | 127 | 107 | 77 | 1¼" 1½" 2" | 1548 | - | 2273 | ||
| - | 4sd10/37 | 7.5 | 10 | 217 | 212 | 206 | 198 | 191 | 182 | 172 | 157 | 139 | 116 | 83 | 1¼" 1½" 2" | 1662 | - | 2387 | ||
