domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | |||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 1.2 | 2.4 | 3.6 | 4.8 | 6 | 7.2 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 20 | 40 | 60 | 80 | 100 | 120 | |||||||||
| 4sdm6/4 | 4sd6/4 | 0.37 | 0.5 | h(m) | 26 | 25 | 23 | 21 | 19 | 15 | 10 | 1¼" 1½" 2" | 348 | 652 | 637 | |
| 4sdm6/6 | 4sd6/6 | 0.55 | 0.75 | 39 | 37 | 34 | 32 | 28 | 22 | 15 | 1¼" 1½" 2" | 409 | 723 | 713 | ||
| 4sdm6/9 | 4sd6/9 | 0.75 | 1 | 59 | 55 | 52 | 47 | 42 | 33 | 23 | 1¼" 1½" 2" | 501 | 835 | 815 | ||
| 4sdm6/12 | 4sd6/12 | 1.1 | 1.5 | 79 | 74 | 69 | 63 | 56 | 45 | 30 | 1¼" 1½" 2" | 593 | 952 | 927 | ||
| 4sdm6/16 | 4sd6/16 | 1.5 | 2 | 105 | 99 | 92 | 84 | 74 | 59 | 40 | 1¼" 1½" 2" | 715 | 1125 | 1075 | ||
| 4sdm6/19 | 4sd6/19 | 2.2 | 3 | 124 | 117 | 109 | 100 | 88 | 70 | 48 | 1¼" 1½" 2" | 807 | 1332 | 1262 | ||
| 4sdm6/22 | 4sd6/22 | 2.2 | 3 | 144 | 136 | 126 | 116 | 102 | 82 | 55 | 1¼" 1½" 2" | 930 | 1455 | 1385 | ||
| - | 4sd6/26 | 3 | 4 | 170 | 160 | 149 | 137 | 121 | 96 | 65 | 1¼" 1½" 2" | 1053 | - | 1547 | ||
| - | 4sd6/30 | 3 | 4 | 196 | 185 | 172 | 158 | 139 | 111 | 75 | 1¼" 1½" 2" | 1175 | - | 1670 | ||
| - | 4sd6/34 | 4 | 5.5 | 223 | 210 | 195 | 179 | 158 | 126 | 85 | 1¼" 1½" 2" | 1298 | - | 1852 | ||
| - | 4sd6/38 | 4 | 5.5 | 249 | 234 | 218 | 200 | 176 | 141 | 95 | 1¼" 1½" 2" | 1420 | - | 1974 | ||
| - | 4sd6/42 | 5.5 | 7.5 | 275 | 259 | 241 | 221 | 195 | 156 | 105 | 1¼" 1½" 2" | 1574 | - | 2209 | ||
| - | 4sd6/46 | 5.5 | 7.5 | 301 | 284 | 263 | 243 | 213 | 171 | 115 | 1¼" 1½" 2" | 1696 | - | 2331 | ||
| - | 4sd6/50 | 7.5 | 10 | 327 | 308 | 286 | 264 | 232 | 185 | 125 | 1¼" 1½" 2" | 1819 | - | 2544 | ||
| - | 4sd6/55 | 7.5 | 10 | 360 | 339 | 315 | 290 | 255 | 204 | 138 | 1¼" 1½" 2" | 1972 | - | 2697 | ||
