domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | |||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 3 | 6 | 9 | 12 | 15 | 18 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 50 | 100 | 150 | 200 | 250 | 300 | |||||||||
| 6srm10/4 | 6sr10/4 | 2.2 | 3 | h(m) | 52 | 49 | 45 | 38 | 31 | 23 | 15 | 2½" 3" | 556 | 1123 | 1113 | |
| 6srm10/6 | 6sr10/6 | 3 | 4 | 78 | 74 | 67 | 58 | 47 | 35 | 22 | 2½" 3" | 635 | 1221 | 1201 | ||
| 6srm10/8 | 6sr10/8 | 4 | 5.5 | 104 | 98 | 89 | 77 | 63 | 46 | 29 | 2½" 3" | 712 | 1378 | 1298 | ||
| 6srm10/11 | 6sr10/11 | 5.5 | 7.5 | 143 | 135 | 122 | 106 | 87 | 64 | 40 | 2½" 3" | 829 | 1545 | 1445 | ||
| - | 6sr10/13 | 7.5 | 10 | 169 | 159 | 145 | 125 | 102 | 75 | 48 | 2½" 3" | 906 | - | 1572 | ||
| - | 6sr10/15 | 7.5 | 10 | 195 | 184 | 167 | 144 | 118 | 87 | 55 | 2½" 3" | 984 | - | 1650 | ||
| - | 6sr10/18 | 9.2 | 12.5 | 234 | 221 | 200 | 173 | 142 | 104 | 66 | 2½" 3" | 1101 | - | 1817 | ||
| - | 6sr10/22 | 11 | 15 | 286 | 270 | 245 | 211 | 173 | 128 | 81 | 2½" 3" | 1256 | - | 2042 | ||
| - | 6sr10/25 | 13 | 17.5 | 325 | 307 | 278 | 240 | 197 | 145 | 92 | 2½" 3" | 1373 | - | 2209 | ||
| - | 6sr10/29 | 15 | 20 | 377 | 356 | 323 | 278 | 228 | 168 | 106 | 2½" 3" | 1528 | - | 2414 | ||
| - | 6sr10/34 | 18.5 | 25 | 442 | 417 | 379 | 326 | 267 | 197 | 125 | 2½" 3" | 1722 | - | 2633 | ||
| - | 6sr10/38 | 22 | 30 | 494 | 466 | 423 | 365 | 299 | 220 | 139 | 2½" 3" | 1878 | - | 2864 | ||
| - | 6sr10/41 | 22 | 30 | 533 | 503 | 456 | 394 | 323 | 238 | 150 | 2½" 3" | 1994 | - | 2980 | ||
