domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | ||||||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 1.2 | 2.4 | 3.6 | 4.8 | 6 | 7.2 | 8.4 | 9.6 | 10.8 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 20 | 40 | 60 | 80 | 100 | 120 | 140 | 160 | 180 | |||||||||
| 4spm8/4 | 4sp8/4 | 0.55 | 0.75 | h(m) | 23 | 22 | 20 | 19 | 18 | 17 | 16 | 15 | 13 | 11 | 1¼" 1½" | 371 | 685 | 675 | |
| 4spm8/5 | 4sp8/5 | 0.75 | 1 | 29 | 27 | 25 | 24 | 23 | 22 | 20 | 19 | 17 | 14 | 1¼" 1½" | 413 | 747 | 727 | ||
| 4spm8/7 | 4sp8/7 | 1.1 | 1.5 | 41 | 38 | 36 | 34 | 32 | 30 | 29 | 27 | 23 | 19 | 1¼" 1½" | 497 | 856 | 831 | ||
| 4spm8/10 | 4sp8/10 | 1.5 | 2 | 58 | 54 | 51 | 48 | 45 | 43 | 41 | 38 | 33 | 27 | 1¼" 1½" | 623 | 1032 | 982 | ||
| 4spm8/15 | 4sp8/15 | 2.2 | 3 | 87 | 81 | 76 | 72 | 68 | 65 | 61 | 57 | 50 | 41 | 1¼" 1½" | 833 | 1357 | 1287 | ||
| - | 4sp8/19 | 3 | 4 | 111 | 103 | 97 | 91 | 86 | 82 | 78 | 72 | 63 | 52 | 1¼" 1½" | 1001 | - | 1495 | ||
| - | 4sp8/22 | 4 | 5.5 | 128 | 119 | 112 | 105 | 100 | 96 | 90 | 83 | 73 | 60 | 1¼" 1½" | 1127 | - | 1681 | ||
| - | 4sp8/26 | 4 | 5.5 | 151 | 141 | 132 | 125 | 118 | 113 | 106 | 99 | 87 | 71 | 1¼" 1½" | 1295 | - | 1849 | ||
| - | 4sp8/32 | 5.5 | 7.5 | 186 | 173 | 163 | 153 | 145 | 139 | 131 | 121 | 107 | 87 | 1¼" 1½" | 1547 | - | 2182 | ||
| - | 4sp8/36 | 5.5 | 7.5 | 209 | 195 | 183 | 173 | 164 | 156 | 147 | 137 | 120 | 98 | 1¼" 1½" | 1715 | - | 2350 | ||
| - | 4sp8/40 | 7.5 | 10 | 233 | 216 | 204 | 192 | 182 | 174 | 164 | 152 | 134 | 109 | 1¼" 1½" | 1883 | - | 2608 | ||
| - | 4sp8/44 | 7.5 | 10 | 256 | 238 | 224 | 211 | 200 | 191 | 180 | 167 | 147 | 120 | 1¼" 1½" | 2051 | - | 2776 | ||
