domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
| item no. | power | deliveryn=2850rpm | size | |||||||||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 | |||||||||
| 4sdm2/6 | 4sd2/6 | 0.25 | 0.33 | h(m) | 42 | 42 | 42 | 41 | 40 | 39 | 37 | 34 | 31 | 28 | 24 | 19 | 14 | 1¼" 1½" 2" | 379 | 669 | 659 | |
| 4sdm2/8 | 4sd2/8 | 0.37 | 0.5 | 56 | 56 | 55 | 55 | 54 | 52 | 49 | 46 | 42 | 37 | 32 | 25 | 19 | 1¼" 1½" 2" | 429 | 734 | 719 | ||
| 4sdm2/11 | 4sd2/11 | 0.55 | 0.75 | 77 | 77 | 76 | 75 | 74 | 71 | 68 | 63 | 57 | 51 | 43 | 35 | 26 | 1¼" 1½" 2" | 504 | 819 | 809 | ||
| 4sdm2/14 | 4sd2/14 | 0.75 | 1 | 98 | 98 | 97 | 96 | 94 | 91 | 86 | 80 | 73 | 64 | 55 | 44 | 33 | 1¼" 1½" 2" | 579 | 914 | 894 | ||
| 4sdm2/17 | 4sd2/17 | 1.1 | 1.5 | 120 | 119 | 118 | 116 | 114 | 110 | 105 | 98 | 88 | 78 | 67 | 54 | 41 | 1¼" 1½" 2" | 654 | 1013 | 988 | ||
| 4sdm2/20 | 4sd2/20 | 1.1 | 1.5 | 141 | 140 | 138 | 137 | 134 | 130 | 124 | 115 | 104 | 92 | 78 | 64 | 48 | 1¼" 1½" 2" | 760 | 1120 | 1095 | ||
| 4sdm2/23 | 4sd2/23 | 1.5 | 2 | 162 | 161 | 159 | 157 | 154 | 149 | 142 | 132 | 119 | 106 | 90 | 73 | 55 | 1¼" 1½" 2" | 835 | 1244 | 1194 | ||
| 4sdm2/26 | 4sd2/26 | 1.5 | 2 | 183 | 182 | 180 | 178 | 174 | 169 | 161 | 149 | 135 | 120 | 103 | 83 | 62 | 1¼" 1½" 2" | 909 | 1319 | 1269 | ||
| 4sdm2/32 | 4sd2/32 | 2.2 | 3 | 225 | 223 | 221 | 219 | 214 | 208 | 198 | 184 | 166 | 147 | 126 | 102 | 76 | 1¼" 1½" 2" | 1059 | 1583 | 1513 | ||
| 4sdm2/38 | 4sd2/38 | 2.2 | 3 | 267 | 265 | 263 | 260 | 254 | 247 | 235 | 218 | 197 | 175 | 150 | 121 | 91 | 1¼" 1½" 2" | 1208 | 1733 | 1663 | ||
| - | 4sd2/44 | 3 | 4 | 309 | 307 | 304 | 301 | 295 | 286 | 272 | 253 | 229 | 202 | 174 | 140 | 105 | 1¼" 1½" 2" | 1389 | - | 1884 | ||
| - | 4sd2/50 | 3 | 4 | 352 | 349 | 346 | 342 | 335 | 325 | 309 | 287 | 260 | 230 | 198 | 159 | 119 | 1¼" 1½" 2" | 1538 | - | 2033 | ||
| - | 4sd2/56 | 4 | 5.5 | 394 | 391 | 387 | 383 | 375 | 364 | 346 | 322 | 291 | 257 | 221 | 178 | 134 | 1¼" 1½" 2" | 1688 | - | 2242 | ||
| - | 4sd2/62 | 4 | 5.5 | 436 | 433 | 429 | 424 | 415 | 403 | 383 | 356 | 322 | 285 | 243 | 197 | 148 | 1¼" 1½" 2" | 1869 | - | 2423 | ||
