domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m.
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital auto-control box.
|
parts name |
material |
|
|
pump external casing |
①aisi 316 ss |
②aisi 304 ss |
|
delivery casing |
①aisi 316 ss |
②aisi 304 ss |
|
suction lattern |
①aisi 316 ss |
②aisi 304 ss |
|
diffusor |
①aisi 316 ss |
②aisi 304 ss |
|
impeller |
①aisi 316 ss |
②aisi 304 ss |
|
pump shaft |
①aisi 316 ss |
②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss |
②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
|
motor external casing |
aisi 304 ss |
|
|
top chock |
①cast-cu astm280 ②cast-iron g20 uni5007 ③aisi 304 ss |
|
|
bottom support |
aisi 304 ss |
|
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
|
motor shaft |
aisi 304 ss-c1045 |
|
|
bearing |
① c&u |
② nsk |
|
seal lubricant oil |
oil of food degree |
|
domestic use.
water supply from wells and pools.
civil and industrial application.
garden use and irrigation.
maximum fluid temperature 50℃.
maximum sand content 0.25%.
maximum immersion 80m
rewindable motor or full screened motor.
3-phase: 380-415v / 50hz, 440v / 60hz, 220v / 60hz.
1-phase: 220v-240v / 50hz, 110-127v / 60hz.
equip with hand-start control box or digital
auto-control box.
|
parts name |
material |
|
pump external casing |
aisi 304 ss |
|
delivery casing |
①cast cu astm280 ② aisi 304 ss |
|
suction lattern |
①cast cu astm280 ② aisi 304 ss |
|
diffusor |
pc |
|
impeller |
pom |
|
pump shaft |
①aisi 316 ss②aisi 304 ss |
|
shaft coupling |
①aisi 316 ss②aisi 304 ss |
|
wear ring |
aisi 304 ss |
|
motor external casing |
aisi 304 ss |
|
top chock |
①cast-cu astm280 ② cast-iron g20 uni5007 |
|
bottom support |
aisi 304 ss |
|
mechanical seal |
special seal for deep well(carbon-sic/tc) |
|
motor shaft |
aisi 304 ss-c1045 |
|
bearing |
① c&u② nsk |
|
seal lubricant oil |
oil of food degree |
| item no. | power | deliveryn=2850rpm | size | |||||||||||||||||||
| 1-phase | 3-phase | kw | hp | q | m³/h | 0 | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | dn | l1 | l(s) | l(t) |
| l/min | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 | |||||||||
| 3sdm1.8/7 | 3sd1.8/7 | 0.18 | 0.25 | h(m) | 29 | 28 | 28 | 27 | 25 | 24 | 21 | 17 | 13 | 8 | - | - | - | 1" | 351 | 651 | 641 | |
| 3sdm1.8/10 | 3sd1.8/10 | 0.25 | 0.33 | 41 | 40 | 40 | 38 | 36 | 34 | 30 | 25 | 19 | 11 | - | - | - | 1" | 418 | 739 | 719 | ||
| 3sdm1.8/14 | 3sd1.8/14 | 0.37 | 0.5 | 57 | 57 | 55 | 54 | 51 | 47 | 42 | 35 | 26 | 16 | - | - | - | 1" | 508 | 849 | 829 | ||
| 3sdm1.8/20 | 3sd1.8/20 | 0.55 | 0.75 | 82 | 81 | 79 | 77 | 73 | 67 | 60 | 49 | 37 | 23 | - | - | - | 1" | 666 | 1027 | 1007 | ||
| 3sdm1.8/27 | 3sd1.8/27 | 0.75 | 1 | 111 | 109 | 107 | 103 | 98 | 91 | 81 | 67 | 50 | 31 | - | - | - | 1" | 823 | 1224 | 1184 | ||
| 3sdm1.8/37 | 3sd1.8/37 | 1.1 | 1.5 | 152 | 150 | 146 | 142 | 135 | 124 | 111 | 91 | 68 | 43 | - | - | - | 1" | 1047 | 1523 | 1448 | ||
| 3sdm1.8/47 | 3sd1.8/47 | 1.5 | 2 | 193 | 190 | 186 | 180 | 171 | 158 | 141 | 116 | 87 | 54 | - | - | - | 1" | 1295 | 1846 | 1771 | ||
| 3sdm2.5/5 | 3sd2.5/5 | 0.18 | 0.25 | 20 | 20 | 20 | 19 | 19 | 18 | 17 | 16 | 15 | 13 | 11 | 9 | 6 | 1" | 323 | 624 | 614 | ||
| 3sdm2.5/7 | 3sd2.5/7 | 0.25 | 0.33 | 28 | 28 | 28 | 27 | 26 | 26 | 24 | 23 | 21 | 18 | 16 | 12 | 9 | 1" | 375 | 696 | 676 | ||
| 3sdm2.5/10 | 3sd2.5/10 | 0.37 | 0.5 | 41 | 40 | 40 | 39 | 38 | 36 | 35 | 32 | 30 | 26 | 22 | 17 | 12 | 1" | 453 | 794 | 774 | ||
| 3sdm2.5/15 | 3sd2.5/15 | 0.55 | 0.75 | 61 | 60 | 59 | 58 | 57 | 55 | 52 | 49 | 44 | 40 | 33 | 26 | 19 | 1" | 583 | 944 | 924 | ||
| 3sdm2.5/20 | 3sd2.5/20 | 0.75 | 1 | 81 | 80 | 79 | 78 | 76 | 73 | 69 | 65 | 59 | 53 | 44 | 35 | 25 | 1" | 736 | 1137 | 1097 | ||
| 3sdm2.5/28 | 3sd2.5/28 | 1.1 | 1.5 | 114 | 112 | 111 | 109 | 106 | 102 | 97 | 91 | 83 | 74 | 62 | 49 | 35 | 1" | 943 | 1419 | 1344 | ||
| 3sdm2.5/36 | 3sd2.5/36 | 1.5 | 2 | 147 | 145 | 143 | 140 | 136 | 131 | 125 | 117 | 107 | 95 | 80 | 63 | 45 | 1" | 1150 | 1702 | 1627 | ||
