can be used to transfer clean water or other liquids similar to water with physical and chemical properties.
suitable for domestic water from the well, sprinkling irrigation in garden , small air conditioning system and supporting equipment,etc.
1. high-quality bearing
2. motor with copper winding
3. built-in thermal heating protector for single phase motor
4. insulation class: f
5. protection class: ipx4
6. max ambient temperature: 40℃
1. cast iron pump head,special anti-rust treatment
2. brass impeller, anti-block system
3. aisi 304 welding shaft
4. max liquid temperature: 60℃
5. max suction: 8m
6. self-priming
|
model |
basic function |
|
mt-x25m mt-x37m mt-x55m mt-x75m |
set on/off pressure of mechanical switch, it can control the start and stop of pump according to pressure change in pipe system. |
|
mt-x25e mt-x37e mt-x55e mt-x75e |
controlled by plc microcomputer chip, can achieve unattended, remote monitoring. it can protect pump from water shortage, rusting, frequent start, block, over-voltage or under-voltage and freezing. meanwhile, it has start delay protection, data protection when power failure and fault alarm. |
|
model |
power |
q(m³/h) |
0 |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
3.0 |
3.6 |
4.2 |
|
|
single phase 220v/50hz |
w |
hp |
q(l/min) |
0 |
5 |
10 |
15 |
25 |
30 |
35 |
40 |
45 |
50 |
55 |
60 |
|
mt-x25m / mt-x25e |
250 |
0.33 |
h (m) |
28 |
23 |
18 |
15 |
11 |
7.5 |
4 |
/ |
/ |
/ |
/ |
/ |
|
mt-x37m / mt-x37e |
370 |
0.5 |
40 |
35 |
28 |
22 |
18 |
12 |
8 |
3 |
/ |
/ |
/ |
/ |
|
|
mt-x55m / mt-x55e |
550 |
0.75 |
45 |
40 |
32 |
28 |
22 |
18 |
12 |
8 |
5 |
/ |
/ |
/ |
|
|
mt-x75m / mt-x75e |
750 |
1.0 |
55 |
50 |
42 |
38 |
32 |
28 |
22 |
18 |
12 |
5 |
/ |
/ |
|
|
model |
l(mm) |
w(mm) |
h(mm) |
n/g.w |
|
mt-x25m |
290 |
274 |
282 |
7.8/8.2 |
|
mt-x37m |
290 |
274 |
282 |
8.2/8.6 |
|
mt-x25e |
320 |
290 |
316 |
9.0/9.4 |
|
mt-x37e |
320 |
290 |
316 |
9.7/10.1 |
|
mt-x55m |
320 |
290 |
282 |
11.2/12 |
|
mt-x75m |
320 |
290 |
282 |
12.4/13.2 |
|
mt-x55e |
320 |
290 |
296 |
12.5/13.1 |
|
mt-x75e |
320 |
290 |
296 |
13.8/14.5 |
