can be used to transfer clean water or other liquids similar to water with physical and chemical properties.
suitable for domestic water from the well, sprinkling irrigation in garden , small air conditioning system and supporting equipment,etc.
1. high-quality bearing
2. motor with copper winding
3. built-in thermal heating protector for single phase motor
4. insulation class: f
5. protection class: ipx4
6. max ambient temperature: 40℃
1. cast iron pump head, special anti-rust treatment
2. brass impeller, anti-block system
3. aisi 304 welding shaft
4. max liquid temperature: 60℃
5. max suction: 8m
|
model |
basic function |
|
mt-q25e |
controlled by plc microcomputer chip, can achieve unattended, remote monitoring. it can protect pump from water shortage, rusting, frequent start, block, over-voltage or under-voltage and freezing. meanwhile, it has start delay protection, data protection when power failure and fault alarm. |
|
mt-q37e |
|
|
mt-q55e |
|
|
mt-q75e |
|
model |
power |
q(m³/h) |
0 |
0.6 |
1.2 |
1.8 |
2.4 |
3.0 |
|
|
single phase 220v/50hz |
w |
hp |
q(l/min) |
0 |
10 |
20 |
30 |
40 |
50 |
|
mt-q25e |
250 |
0.33 |
h (m) |
28 |
19 |
12 |
5 |
/ |
/ |
|
mt-q37e |
370 |
0.5 |
40 |
30 |
20 |
10 |
3 |
/ |
|
|
mt-q55e |
550 |
0.75 |
60 |
50 |
35 |
25 |
10 |
5 |
|
|
mt-q75e |
750 |
1.0 |
75 |
60 |
45 |
28 |
15 |
5 |
|
|
model |
l(mm) |
w(mm) |
h(mm) |
n/g.w |
|
mt-q25e |
275 |
150 |
320 |
5.3/5.8 |
|
mt-q37e |
275 |
150 |
320 |
6.0/6.5 |
|
mt-q55e |
320 |
170 |
330 |
9.3/10.8 |
|
mt-q75e |
320 |
170 |
330 |
10.7/11.2 |
