hfm/5b
hfm/6a
◎ max. suction: 8m
◎ max. medium temperature 60℃
◎ max. ambient temperature 40℃
◎ max pressure: 8bar
◎ single phase/three phase, 50/60hz(on demand)
◎ thermal protector for single phase
◎ insulation class: b
◎ protection class: ipx4
|
model |
power |
q.max |
h.max |
s.max |
inlet/outlet |
g.w |
packing dimension |
20gp |
|
|
(kw) |
(hp) |
(m³/h) |
(m) |
(m) |
(inch) |
(kg) |
(mm) |
(pcs) |
|
|
hfm/5c |
0.55 |
0.75 |
30 |
12.5 |
8 |
2”×2” |
14.8 |
355×220×270 |
1300 |
|
hfm/5b |
0.75 |
1 |
30 |
14 |
8 |
2”×2” |
15.7 |
355×220×270 |
1200 |
|
hfm/5a |
1.1 |
1.5 |
36 |
15 |
8 |
2”×2” |
16.3 |
425×220×310 |
970 |
|
hfm/5bm |
1.1 |
1.5 |
30 |
23.5 |
8 |
2”×2” |
19 |
425×220×310 |
960 |
|
hfm/5am |
1.5 |
2 |
36 |
25.5 |
8 |
2”×2” |
21 |
425×220×310 |
950 |
|
hfm/6c |
1.1 |
2 |
60 |
12 |
8 |
3”×3” |
29 |
475×290×350 |
600 |
|
hfm/6cr |
1.1 |
2 |
60 |
12 |
8 |
4”×4” |
30 |
475×290×350 |
600 |
|
hfm/6b |
1.5 |
2 |
66 |
14.7 |
8 |
3”×3” |
30 |
500×290×360 |
500 |
|
hfm/6br |
1.5 |
2 |
66 |
14.7 |
8 |
4”×4” |
31 |
500×290×360 |
500 |
|
hfm/6a |
2.2 |
3 |
72 |
18.5 |
8 |
3”×3” |
38 |
500×290×360 |
500 |
|
hfm/6ar |
2.2 |
3 |
72 |
18.5 |
8 |
4”×4” |
39 |
500×290×360 |
500 |
|
hfm/7br |
3 |
4 |
78 |
22 |
8 |
4”×4” |
42 |
500×290×360 |
450 |
