vpm series clean water submersible pump is the most extensively used pump suitable for arable land irrigation, mine water drainage, as well as for flood control campaign, it is compact inconstruction, tight in sealing quality, high efficiency in energy conservation, and long durability for use as well. it is suitable for river, lake and well etc
suitable fluids: clean water fluid temperature
range: 0~40℃
max.working pressure: 8bar
single phase: 220v±5%/50hz
degree of protection: ip68
insulation class: b
pump body: aluminium motor
body: aluminium
impeller: rubber
shaft: 45#steel
|
model |
powe |
r |
flow |
head |
outlet |
weight |
diameter |
dimensions |
|
kw |
hp |
(l/min) |
(m) |
(mm) |
(kg) |
|
(cm) |
|
|
vpm60 |
0.25 |
0.33 |
18 |
70 |
1/2 |
4.0 |
100 |
295x115x155 |
|
vpm60-1 |
0.25 |
0.33 |
18 |
70 |
1/2 |
4.0 |
100 |
295x115x155 |
