wastewater drainage in factories,construction sites and commercial facilities
drainage system in municipal sewage treatment plants
drainage station in residential quarters
methane pools and field irrigation in countryside
municipal projects
max immersion depth:5m
max liquid temperature: 40℃
liquid ph value:5-9
liquid kinematic ciscosity:7x10-6 ~23x10-6 m²/s
max.liquid density:1.2×10³ kg/m³
copper winding
built-in thermal protector
stainless steel welded shaft
insulation class: b
protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max. head (m) |
g.w (kg) |
dimensions (cm) |
|
mt-kpwm750d |
0.75 |
40 |
220v/50hz |
200 |
14 |
22.5 |
26.8x15.2x41.3 |
|
mt-kpwm1100d |
1.1 |
40 |
220v/50hz |
233 |
19 |
26 |
26.8x15.2x41.3 |
|
mt-kpwm1300d |
1.3 |
50 |
220v/50hz |
250 |
22 |
29.5 |
26.8x15.2x44.2 |
|
mt-kpwm1500d |
1.5 |
50 |
220v/50hz |
250 |
26 |
30 |
26.8x15.2x44.2 |
|
mt-kpwm2200d |
2.2 |
65 |
220v/50hz |
300 |
30 |
33.5 |
29.0x16.6x44.2 |
|
no. |
name |
material/spec. |
|
1 |
cable components |
|
|
model |
|
|
|
mt-kpw750d |
cable---h07 rn-f4gx1mm²x6m |
|
|
mt-kpwm1100d/mt-kpwm1300d |
cable---h07rn-f3gx1.5mm²x1m 4gx1.5mm²x5m |
|
|
mt-kpwm1500d/mt-kpwm2200d |
cable---h07rn-f3gx2mm²x1m 4gx2mm²x5m |
|
|
resin sealing |
pa66(epoxy resin casing) |
|
|
2 |
handle |
aisi201 |
|
3 |
capacitor cover |
ht200 |
|
4 |
bearing |
nsk |
|
5 |
pump body |
ht200 |
|
6 |
motor |
copper winding |
|
7 |
rotor |
45#carbon steel&2cr13 stainless |
|
8 |
bearing |
nsk |
|
9 |
bearing pedestal |
zl102 |
|
10 |
double mechanical seal |
mtu |
|
11 |
cylinder cover |
ht200 |
|
12 |
impeller |
ht200 |
|
13 |
base plate |
ht200 |
|
14 |
rotation cutter |
9cr18 |
|
15 |
fixed cutter |
4cr13 |
|
16 |
float switch (optional) |
|
