wastewater drainage in factories,construction sites and commercial facilities
drainage system in municipal sewage treatment plants
drainage station in residential quarters
methane pools and field irrigation in countryside
municipal projects
max immersion depth:5m
max liquid temperature: 40℃
liquid ph value:5-9
liquid kinematic ciscosity:7x10-6 ~23x10-6 m²/s
max.liquid density:1.2×10³ kg/m³
copper winding
built-in thermal protector
stainless steel welded shaft
insulation class: b
protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max.head (m) |
g.w (kg) |
dimensions (cm) |
|
mt-v2200d |
2.2 |
75 |
220v/50hz |
520 |
10 |
31.5 |
59.0x35.5x25.0 |
|
no. |
name |
material/spec. |
|
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
ht200 |
|
|
3 |
motor |
aisi201（ motor casing） |
|
|
4 |
float switch (optional) |
||
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
ht200 |
|
|
8 |
rotation cutter |
9cr18 |
|
|
9 |
fixed cutter |
45# |
|
|
10 |
oil seal |
nbr |
|
|
11 |
double mechanical seal |
mtu |
|
|
12 |
bearing |
nsk |
|
|
13 |
rotor |
45#carbon steel&2cr13 stainless |
|
|
14 |
bearing |
nsk |
|
|
15 |
upper cover |
ht200 |
|
|
16 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-v2200d |
50uf/450vac |
s0 |
|
|
17 |
cable components |
||
|
model |
|||
|
mt-v2200d |
cable---h07 rn-f3gx2mm2 x6m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
18 |
out-let connector |
abs(g2½) |
|
|
19 |
flange connector |
ht200 |
|
