wastewater drainage in factories,construction sites and commercial facilities
drainage system in municipal sewage treatment plants
drainage station in residential quarters
methane pools and field irrigation in countryside
municipal projects
max immersion depth:5m
max liquid temperature: 40℃
liquid ph value:5-9
liquid kinematic ciscosity:7x10-6 ~23x10-6 m²/s
max.liquid density:1.2×10³ kg/m³
copper winding
built-in thermal protector
stainless steel welded shaft
insulation class: b
protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max.head (m) |
max.diameter of particle (mm) |
g.w (kg) |
dimensions (cm) |
|
mt-wqd25-8-1.1 |
1.1 |
75 |
220v/50hz |
766 |
13 |
50 |
32 |
35.0x27.0x50.0 |
|
mt-wqd27-9-1.5 |
1.5 |
75 |
220v/50hz |
833 |
15 |
50 |
32.5 |
35.0x27.0x50.0 |
|
mt-wqd30-11-2.2 |
2.2 |
75 |
220v/50hz |
966 |
20 |
50 |
33 |
35.0x27.0x50.0 |
|
no. |
name |
material/spec. |
|
1 |
handle |
aisi201&pa66 |
|
2 |
motor casing |
ht200 |
|
3 |
motor |
copper winding |
|
4 |
bearing pedestal |
ht200 |
|
5 |
out-let connector |
abs (g2½ ) |
|
6 |
pump body |
ht200 |
|
7 |
base plate |
aisi304 |
|
8 |
impeller |
aisi201 |
|
9 |
oil seal |
nbr |
|
10 |
double mechanical seal |
mtu |
|
11 |
bearing |
nsk |
|
12 |
rotor |
45#carbon steel&2cr13 stainless |
|
13 |
bearing |
nsk |
|
14 |
cable components |
|
|
model |
|
|
|
mt-wqd25-8-1.1 |
cable---h07 rn-f3gx1.5mm2 x6m |
|
|
mt-wqd27-9-1.5 |
cable---h07 rn-f3gx2mm2 x6m |
|
|
mt-wqd30-11-2.2 |
cable---h07 rn-f3gx2mm2 x6m |
|
|
cable shield |
neoprene |
|
|
gland nut |
aisi201 |
|
