wastewater drainage in factories,construction sites and commercial facilities
drainage system in municipal sewage treatment plants
drainage station in residential quarters
methane pools and field irrigation in countryside
municipal projects
max immersion depth:5m
max liquid temperature: 40℃
liquid ph value:5-9
liquid kinematic ciscosity:7x10-6 ~23x10-6 m²/s
max.liquid density:1.2×10³ kg/m³
copper winding
built-in thermal protector
stainless steel welded shaft
insulation class: b
protection class:ipx8
|
产品型号 model |
功率power (kw) |
排出口径outlet diameter (mm) |
电压/频率voltage/ frequency |
最大流量max.flow (l/min) |
最大扬程max.head (m) |
最大颗粒直径max.diameter of particle (mm) |
毛重 g.w (kg) |
尺寸dimensions (cm) |
|
mt-v1500b |
1.5 |
50 |
220v/50hz |
450 |
18.5 |
20 |
28 |
60.0x36.2x26.5 |
|
mt-v2200 |
2.2 |
75 |
220v/50hz |
700 |
17 |
20 |
33.0 |
60.0x36.2x26.5 |
|
no. |
name |
material/spec. |
|
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
ht200 |
|
|
3 |
motor |
aisi201（motor casing） |
|
|
4 |
float switch (optional) |
||
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
ht200 |
|
|
8 |
oil seal |
nbr |
|
|
9 |
cylinder cover |
ht200 |
|
|
10 |
double mechanical seal |
mtu |
|
|
11 |
flange connector |
ht200(mt-1500b无此零件 without this part) |
|
|
12 |
out-let connector |
abs (mt-v1500b:g2,mt-v2200:g2½) |
|
|
13 |
bearing |
nsk |
|
|
14 |
rotor |
45#carbon steel&2cr13 stainless |
|
|
15 |
bearing |
nsk |
|
|
16 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-v1500b/mt-v2200 |
50uf/450vac |
s0 |
|
|
17 |
cable components |
||
|
model |
|||
|
mt-v1500b/mt-v2200 |
cable---h07 rn-f3gx2mm2 x6m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
18 |
upper cover |
ht200 |
|
|
19 |
pump cover |
ht200 |
|
|
20 |
filter mesh |
aisi304 |
|
