wastewater drainage in factories,construction sites and commercial facilities
drainage system in municipal sewage treatment plants
drainage station in residential quarters
methane pools and field irrigation in countryside
municipal projects
max immersion depth:5m
max liquid temperature: 40℃
liquid ph value:5-9
liquid kinematic ciscosity:7x10-6 ~23x10-6 m²/s
max.liquid density:1.2×10³ kg/m³
copper winding
built-in thermal protector
stainless steel welded shaft
insulation class: b
protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max.head (m) |
max.diameter of particle (mm) |
g.w (kg) |
dimensions (cm) |
|
mt-v180 |
0.18 |
32 |
220v/50hz |
133 |
7 |
15 |
9.0 |
20.0x19.0x39.0 |
|
mt-v250 |
0.25 |
32 |
220v/50hz |
150 |
7.5 |
15 |
9.5 |
20.0x19.0x40.0 |
|
mt-v450 |
0.45 |
50 |
220v/50hz |
200 |
8.5 |
25 |
17.5 |
27.0x20.7x52.0 |
|
mt-v750 |
0.75 |
50 |
220v/50hz |
300 |
10.5 |
25 |
22 |
27.0x20.7x56.0 |
|
no. |
name |
material/spec. |
|
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
ht200 |
|
|
3 |
motor |
aisi201 (motor casing) |
|
|
4 |
float switch (optional) |
||
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
( pa66 ) optionalht200 |
|
|
8 |
oil seal |
nbr |
|
|
9 |
cylinder cover |
ht200 |
|
|
10 |
out-let connector |
abs(g1 ¼ ) |
|
|
11 |
double mechanical seal |
mtu |
|
|
12 |
bearing |
nsk |
|
|
13 |
rotor |
45#carbon steel& 2cr13 stainless |
|
|
14 |
bearing |
nsk |
|
|
15 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-v180 |
8uf/450vac |
s0 |
|
|
mt-v250 |
10uf/450vac |
s0 |
|
|
16 |
cable components |
||
|
mt-v180/mt-v250 |
cable---h05rn-f3gx0.5mm2 x6m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
no. |
name |
material/spec. |
|
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
ht200 |
|
|
3 |
motor |
aisi201 (motor casing) |
|
|
4 |
float switch (optional) |
||
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
ht200 |
|
|
8 |
oil seal |
nbr |
|
|
9 |
cylinder cover |
ht200 |
|
|
10 |
double mechanical seal |
mtu |
|
|
11 |
flange connector |
ht200 |
|
|
12 |
out-let connector |
abs (g2) |
|
|
13 |
bearing |
nsk |
|
|
14 |
rotor |
45#carbon steel&2cr13 stainless |
|
|
15 |
bearing |
nsk |
|
|
16 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-v450 |
15uf/450vac |
s0 |
|
|
mt-v750 |
20uf/450vac |
s0 |
|
|
17 |
cable components |
||
|
mt-v450 |
cable---h07 rn-f3gx0.75mm2 x6m |
||
|
mt-v750 |
cable---h07 rn-f3gx1mm2x6m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
18 |
upper cover |
ht200 |
|
|
19 |
base plate |
ht200 |
|
