can be used to transfer clean water or other liquids similar to water with physical and chemical properties.
suitable for domestic water from the well, sprinkling irrigation in garden , small air conditioning system and supporting equipment,etc
1. high-quality bearing
2. motor with copper winding
3. built-in thermal heating protector for single phase motor
4. insulation class: f
5. protection class: ipx4
6. max ambient temperature: 40℃
1. cast iron pump head, special anti-rust treatment
2. ppo impeller/brass impeller/ss impeller
3. aisi 304 welding shaft
4. max liquid temperature: 60℃
5. max suction: 9.5m
|
model |
power |
a type b type |
q(m³/h) |
0 |
0.6 |
1.2 |
1.8 |
2.4 |
3.0 |
3.6 |
3.8 |
4.2 |
4.5 |
|
|
single phase 220v/50hz |
w |
hp |
q(l/min) |
0 |
10 |
20 |
30 |
40 |
50 |
60 |
63 |
70 |
75 |
|
|
mt-jc-550 |
550 |
0.75 |
a |
h (m) |
44 |
34 |
25 |
20 |
3 |
/ |
/ |
/ |
/ |
/ |
|
b |
40 |
35 |
30 |
25 |
10 |
3 |
/ |
/ |
/ |
/ |
||||
|
mt-jc-750 |
750 |
1 |
a |
47 |
40 |
38 |
25 |
20 |
5 |
/ |
/ |
/ |
/ |
|
|
b |
43 |
37 |
30 |
28 |
22 |
15 |
3 |
/ |
/ |
/ |
||||
|
mt-jc-1100 |
1100 |
1.5 |
a |
50 |
43 |
38 |
30 |
28 |
22 |
8 |
3 |
/ |
/ |
|
|
b |
45 |
42 |
38 |
36 |
30 |
26 |
25 |
22 |
16 |
3 |
||||
|
model |
l(mm) |
w(mm) |
h(mm) |
n/g.w(a) |
n/g.w(b) |
|
mt-jc-550 |
495 |
205 |
305 |
14.7/16 |
14.4/15.7 |
|
mt-jc-750 |
495 |
205 |
305 |
15.3/16.6 |
15/16.3 |
|
mt-jc-1100 |
495 |
205 |
305 |
15.9/17.2 |
15.6/16.9 |
