transport clear water and other liquids similar to water. it is suitable for household water supply, well water lifting, tap water pressurization, garden automatic irrigation system, small air conditioning system or supporting facilities, etc. it is especially suitable for water heater pipeline pressurization with insufficient water pressure to prevent the phenomenon of water supply cold and hot.
1. nsk bearing
2. motor with copper winding
3. three phase 220v motor with thermal protector
4. insulation class:f
5. protection class:ipx4
6. max ambient temperature: 40℃
1. compact structure, low noise
2. ss 304 welding shaft
3. brass impeller
4. pump electrophoresis
5. italy mechanical seal
6. max suction:8m
7. liquid temperature:0-99℃
8. max pressure:1mpa
|
model |
power |
q(m³/h) |
0 |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
3.0 |
3.6 |
4.2 |
|
|
single phase 220v/50hz |
w |
hp |
q(l/min) |
0 |
5 |
10 |
15 |
25 |
30 |
35 |
40 |
45 |
50 |
55 |
60 |
|
mt-ex-25 |
250 |
0.4 |
h (m) |
28 |
23 |
18 |
15 |
11 |
7 |
4 |
|
|
|
|
|
|
mt-ex-37 |
370 |
0.6 |
40 |
35 |
28 |
22 |
18 |
12 |
8 |
3 |
/ |
/ |
/ |
/ |
|
|
mt-ex-55 |
550 |
0.8 |
45 |
40 |
32 |
28 |
22 |
18 |
12 |
8 |
5 |
/ |
/ |
/ |
|
|
mt-ex-75 |
750 |
1.0 |
55 |
50 |
42 |
38 |
32 |
28 |
22 |
18 |
12 |
5 |
/ |
/ |
|
|
mt-ex-90 |
900 |
1.2 |
65 |
60 |
55 |
50 |
45 |
40 |
35 |
30 |
25 |
20 |
10 |
5 |
|
1. constant pressure energy saving: the pump can automatically adjust the speed of the pump according to the size of water consumption, so as to achieve the goal of constant pressure energy saving.
2. low noise: the internal flow passage of the pump is optimized by software, which makes the noise of the pump very low in normal use.
3. tube burst protection: when the pipeline pressure is less than 30% of the set pressure, the pump enters the burst protection state to avoid serious losses caused by pipeline rupture.
4. water shortage protection: when there is no water in the intake of the pump, the pump shuts down, and when there is water in the pipeline, the pump resumes its normal working state.
5. over-current protection: when the current of the pump is too high due to the faults such as blocking and short circuit, the pump will stop automatically to prevent the damage of the frequency inverter.
6. multiple protection: pump has many protection functions, such as card protection, over-voltage protection, over-current protection, under-voltage protection, stop-up protection, lightning protection, water shortage protection, ipm module protection, over-temperature protection, burst protection and so on, to protect you and your family.
|
model |
l(mm) |
w(mm) |
h(mm) |
n/g.w |
|
mt-ex-25 |
290 |
260 |
280 |
7.0/7.7 |
|
mt-ex-37 |
290 |
260 |
280 |
7.6/8.3 |
|
mt-ex-55 |
290 |
260 |
280 |
11.4/12.4 |
|
mt-ex-75 |
340 |
290 |
290 |
12.2/13.2 |
|
mt-ex-90 |
340 |
290 |
290 |
12.8/13.8 |
