can be used to transfer clean water or other liquids similar to water with physical and chemical properties.
suitable for domestic water from the well, sprinkling irrigation in garden , small air conditioning system and supporting equipment,etc.
1. high-quality bearing
2. motor with copper winding
3. built-in thermal heating protector for single phase motor
4. insulation class: f
5. protection class: ipx4
6. max ambient temperature: 40℃
1. cast iron pump head, special anti-rust treatment
2. ppo impeller/brass impeller/ss impeller
3. aisi 304 welding shaft
4. liquid temperature: 0-99℃
5. max suction: 9.5m
6. max working pressure: 8bar
|
model |
basic function |
special function |
|
mt-jca-550 mt-jca-750 mt-jca-1100 |
automatic control the start and stop of water pump; stop water pump when water is shortage, and it can detect and reset automatically; built-in buffer tank, no frequent start and stop. |
/ |
|
mt-jca-550h mt-jca-750h mt-jca-1100h |
used for liquid temperature 0-99℃ |
|
|
mt-(a)jca-550 mt-(a)jca-750 mt-(a)jca-1100 |
remote monitoring to check the operation state of water pump by mobile phone; remote control start and stop by mobile phone; |
|
model |
power |
a type b type |
q(m³/h) |
0 |
0.6 |
1.2 |
1.8 |
2.4 |
3.0 |
3.6 |
3.8 |
4.2 |
|
|
single phase 220v/50hz |
w |
hp |
q(l/min) |
0 |
10 |
20 |
30 |
40 |
50 |
60 |
63 |
70 |
|
|
mt-jca-550 |
550 |
0.75 |
a |
h (m) |
43 |
34 |
25 |
20 |
3 |
/ |
/ |
/ |
/ |
|
mt-(a)jca-550 |
|||||||||||||
|
b |
38 |
35 |
30 |
25 |
10 |
3 |
/ |
/ |
/ |
||||
|
mt-jca-550h |
|||||||||||||
|
mt-jca-750 |
750 |
1 |
a |
45 |
40 |
38 |
25 |
20 |
17 |
/ |
/ |
/ |
|
|
mt-(a)jca-750 |
|||||||||||||
|
b |
42 |
37 |
30 |
28 |
22 |
17 |
3 |
/ |
/ |
||||
|
mt-jca-750h |
|||||||||||||
|
mt-jca-1100 |
1100 |
1.5 |
a |
49 |
43 |
38 |
30 |
28 |
22 |
8 |
3 |
/ |
|
|
mt-(a)jca-1100 |
|||||||||||||
|
b |
45 |
40 |
35 |
30 |
25 |
20 |
16 |
13 |
3 |
||||
|
mt-jca-1100h |
|||||||||||||
|
model |
l(mm) |
w(mm) |
h(mm) |
n/g.w(a) |
n/g.w(b) |
|
mt-jca-550 series |
505 |
205 |
330 |
15.7/17 |
14.9/16.2 |
|
mt-jca-750 series |
505 |
205 |
330 |
16.3/17.6 |
15.5/16.8 |
|
mt-jca-1100 series |
505 |
205 |
330 |
16.9/18.2 |
16.1/17.4 |
