normal action process: open faucet, pump starts working;
close faucet, pump stops automatically after 8 seconds delay;
open faucet again, pump automatically starts when pipe system pressure decreases to setting pressure.
max. suction: 9m max.
medium temperature 60℃
max. ambient temperature 40℃
max pressure: 8bar
automatic control
water shortage protection
anti-rust protection
leakage protection
lightning protection
plug and play
man-machine interaction
quiet and comfortable
over-heat protection
flow sensor stuck protection
single phase, 50/60hz(on demand)
thermal protector for single phase insulation class: b
protection class: ipx4
|
model |
power |
q.max |
h.max |
s.max |
inlet/outlet |
g.w |
packing dimension |
20gp |
|
|
(kw) |
(hp) |
(l/min) |
(m) |
(m) |
(inch) |
(kg) |
(mm) |
(pcs) |
|
|
mt-xa-22 |
0.37 |
0.5 |
35 |
35 |
9 |
1"×1" |
7.0 |
260×190×270 |
2000 |
|
mt-xa-52 |
0.55 |
0.75 |
45 |
40 |
9 |
1"×1" |
9.5 |
260×190×270 |
2000 |
|
mt-xa-72 |
0.75 |
1 |
55 |
52 |
9 |
1"×1" |
10 |
260×190×270 |
2000 |
|
model |
f(mm) |
h1(mm) |
h2(mm) |
h3(mm) |
i(mm) |
n(mm) |
n1(mm) |
w(mm) |
|
mt-xa-22 |
206 |
63 |
174 |
204 |
182 |
120 |
106 |
40 |
|
mt-xa-52 |
216 |
63 |
174 |
210 |
182 |
120 |
106 |
40 |
|
mt-xa-72 |
231 |
63 |
174 |
210 |
182 |
120 |
106 |
40 |
