◆small electrical irrigation and drainage equipments
◆particularly applied in urban well water pumping, field irrigation and drainage, garden irrigation and household water supply, as well as drainage of industrial accumulated water, water supply and drainage for construction livestock breeding, etc
◆max immersion depth:5m
◆max liquid temperature: 40℃
◆copper winding
◆built-in thermal protector
◆insulation class: b
◆protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max.head (m) |
g.w (kg) |
dimensions (cm) |
|
mt-spa500b |
0.5 |
50 |
220v/50hz |
210 |
12 |
14 |
26.0x23.5x45.0 |
|
mt-spa750b |
0.75 |
75 |
220v/50hz |
250 |
18 |
20.5 |
33.0x23.5x46.0 |
|
no. |
name |
material/spec. |
|
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
lz102 |
|
|
3 |
motor |
lz102（motor casing） |
|
|
4 |
float switch (optional) |
|
|
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
pp |
|
|
8 |
filter mesh |
pvc |
|
|
9 |
oil seal |
nbr |
|
|
10 |
double mechanical seal |
mtu |
|
|
11 |
bearing |
nsk |
|
|
12 |
rotor |
45#碳钢 45#carbon steel |
|
|
13 |
bearing |
nsk |
|
|
14 |
upper cover |
zl102 |
|
|
15 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-spa500b |
18uf/450vac |
s0 |
|
|
mt-spa750b |
20uf/450vac |
s0 |
|
|
cable components |
|||
|
model |
|
||
|
mt-spa500b |
cable---h07 rn-f3gx0.75mm²x10m |
||
|
mt-spa750b |
cable---h07 rn-f3gx1mm²x10m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
17 |
out-let connector |
abs(mt-spa500b:g2/mt-spa750b:g2½) |
|
|
18 |
flange connector |
ht200 |
|
