small electrical irrigation and drainage equipments particularly applied in urban well water pumping, field irrigation and drainage, garden irrigation and household water supply, as well as drainage of industrial accumulated water, water supply and drainage for construction livestock breeding, etc
max immersion depth:5m
max liquid temperature: 40℃
copper winding
built-in thermal protector
insulation class: b
protection class:ipx8
|
model |
power (kw) |
outlet diameter (mm) |
voltage/ frequency |
max.flow (l/min) |
max.head (m) |
g.w (kg) |
dimensions (cm) |
|
mt-spa6-23/2-0.75a |
0.75 |
50 |
220v/50hz |
200 |
25 |
22.5 |
63.0x30.0x22.5 |
|
mt-spa6-28/2-1.1a |
1.1 |
50 |
220v/50hz |
250 |
30 |
23.0 |
63.0x30.0x22.5 |
|
mt-spa6-39/3-1.5a |
1.5 |
50 |
220v/50hz |
240 |
42 |
29.5 |
63.0x30.0x24.5 |
|
mt-spa6-50/4-1.8a |
1.8 |
50 |
220v/50hz |
240 |
55 |
32.5 |
63.0x30.0x25.5 |
|
no. |
name |
|
material/spec. |
|
1 |
handle |
aisi201 |
|
|
2 |
capacitor cover |
ht200 |
|
|
3 |
motor |
aisi201（ motor casing） |
|
|
4 |
float switch (optional) |
|
|
|
5 |
connecting base |
ht200 |
|
|
6 |
pump body |
ht200 |
|
|
7 |
impeller |
ht200 |
|
|
8 |
pump cover |
ht200 |
|
|
9 |
filter mesh |
aisi304 |
|
|
10 |
guide vane |
ht200 |
|
|
11 |
oil seal |
nbr |
|
|
12 |
double mechanical seal |
mtu |
|
|
13 |
bearing |
nsk |
|
|
14 |
rotor |
45#carbon steel |
|
|
15 |
bearing |
nsk |
|
|
16 |
upper cover |
ht200 |
|
|
17 |
capacitor |
||
|
model |
capacity |
grade |
|
|
mt-spa6-23/2-0.75a |
20uf/450vac |
s0 |
|
|
mt-spa6-28/2-1.1a |
30uf/450vac |
s0 |
|
|
mt-spa6-39/3-1.5a/mt-spa6-50/4-1.8a |
50uf/450vac |
s0 |
|
|
18 |
cable components |
||
|
model |
|
||
|
mt-spa6-23/2-0.75a |
cable---h07 rn-f3gx1mm²x10m |
||
|
mt-spa6-28/2-1.1a |
cable---h07 rn-f3gx1.5mm²x10m |
||
|
mt-spa6-39/3-1.5a/mt-spa6-50/4-1.8a |
cable---h07 rn-f3gx2mm²x10m |
||
|
cable shield |
neoprene |
||
|
flange |
aisi304 |
||
|
19 |
out-let connector |
abs(g2) |
|
