heating water to vd 12035
heating water water/glycol
mixtures max.mixing ratio 1:1
permissible up to:40℃
fluid temperature range:-10℃- 110℃
max.working pressure:10bar
degree of protection:ip44
insulation class:f
pump body: castiron
impeller: pp
shaft: ceramic
bearings: ceramic
pump shaft in the horizontal plane
mains power: 1~230v,50hz
screwed end single head pump
manual 3-speed control
non-overloading single phase motor cast iron body,180mm port-to port
cast iron body,130mm port-to port
|
model |
power |
q.max |
h.max |
inlet/outlet |
pump body length |
nw |
packing dimension |
20gp |
|
|
w |
(l/min) |
(m) |
(inch) |
(mm) |
(kg) |
(mm) |
(pcs/ctn) |
(pcs) |
|
|
xps12/9z-160 |
100 |
23 |
9 |
3/4” |
155 |
2.5 |
365x295x310 |
8 |
7000 |
|
xps20/12z-205 |
200 |
50 |
12 |
1” |
205 |
5.5 |
415x305x190 |
4 |
4200 |
|
xps20/15z-205 |
300 |
60 |
15 |
1” |
205 |
6.5 |
365x295x310 |
4 |
4200 |
|
model |
power |
max.flow |
max.head |
inlet/outlet |
nw |
|
w |
l/min |
(m) |
(inch) |
(kg) |
|
|
xps25/4g-130 |
72/53/38 |
49/35/21 |
4.5/4/3 |
1½” |
2.3 |
|
xps25/4g-180 |
72/53/38 |
57/39/21 |
4.5/4/3 |
1½” |
2.4 |
|
xps15/4g |
72/53/38 |
39/29/18 |
4.5/4/3 |
1 |
2.2 |
|
xps25/6g-130 |
93/67/46 |
55/38/22 |
6/5/3 |
1½” |
2.4 |
|
xps25/6g-180 |
93/67/46 |
69/48/26 |
6/5/3 |
1½” |
2.5 |
