can be used to transfer clean water or other liquids similar to water in physical and chemical properties. suitable for industrial use and urban water supply, pressure boosting for high building and fire fighting, garden irrigation, long-distance water transfer,heating ventilation and air controlling, circulation and pressure boosting for cold and hot water,supporting equipment, etc.
1. high-quality bearing
2. motor with copper winding
3. built-in thermal heating protector for single phase motor
4. insulation class: f
5. protection class: ipx4
6. max ambient temperature: 40℃
1. cast iron pump head, special anti-rust treatment
2. ppo impeller/ss impeller/brass impeller
3. aisi 304 welding shaft
4. max liquid temperature：60℃
5. max suction： 8m
6. max working pressure: 8bar
|
model |
power |
max.flow |
max.head |
suction |
inlet/outlet |
g.w |
dimensions |
|
|
kw |
hp |
(l/min) |
(m) |
(m) |
(inch) |
(kg) |
(cm) |
|
|
mt-cpm130 |
0.37 |
0.5 |
90 |
22 |
8 |
1"×1" |
9 |
28×19×24 |
|
mt-cpm146 |
0.55 |
0.75 |
100 |
26 |
8 |
1"×1" |
12 |
32×20×25.5 |
|
mt-cpm158 |
0.75 |
1 |
120 |
32 |
8 |
1"×1" |
14 |
32×21×27 |
|
mt-cpm170 |
1.1 |
1.5 |
130 |
38 |
8 |
1"×1" |
20 |
36×26×32.5 |
|
mt-cpm200 |
1.5 |
2 |
130 |
42 |
8 |
1"×1" |
21 |
36×26×32.5 |
|
mt-2cpm140 |
1.1 |
1.5 |
105 |
45 |
8 |
1¼"×1" |
23.5 |
42×23×28 |
|
mt-2cpm160 |
1.5 |
2 |
130 |
55 |
8 |
1¼"×1" |
25 |
45×25×31 |
